Regular price $8,007.00 Sale

Recommended for 1-2 Surgeries

Fitted with ISO 6 Hydrocyclone Amalgam Retention

- ISO 11143 Compliant

- Max Flow = 18 l/min (Inverter control Max. flow 916 l/min)

- Min Flow = 0.5 l/min

- Max. vacuum for continuous duty = 210 mBar

- Sound 52 dB(A) (how quiet is that?)

- Power 5.8A, 0.9 kW

- Dimensions H=470 W=420 D=360 mm

- Net weight 23 kg

Cattani’s newest addition to the SMART suction range, the Cube, breaks new ground. When compared to a standard SMART equivalent, Cube delivers increased performance and efficiency with even lower power consumption in a more compact design. Encased in a compact enclosure, the Cube is also whisper-quiet in operation. On-board active ventilation ensures the equipment does not overheat when installed correctly. Developed with environmental sustainability in mind, materials were chosen during development for their performance, production and recycling values

MICRO SMART is a semi wet suction system with INVERTER control. It is our most versatile suction system known for its consistent high performance and can be supplied in many configurations to suit your suction requirements. Their superior design, mechanical precision and robust components result in all SMART suction systems being backed by a 3-year parts and labour warranty.

What is inverter control? Inverter control optimises performance and efficiency. The principle is simple: the inverter is an electronic control that can vary the speed, and therefore the output of the electric suction unit. It adjusts the power used to suit the actual requirements of the clinic – no more, no less!

Connecting a number of SMART suction systems together in parallel is a ‘plug and play’ exercise. With the inverters monitoring the system in harmony, parallel connection has never been so simple.

The Cattani Hydrocyclone is a simple and effective amalgam retention unit that fully integrates with our SMART suction systems. It simply utilises the fluid pressure created by the suction system to achieve 98% amalgam retention in accordance to ISO 11143... all without the need for any moving parts! If you want to watch a short video on how it works then click here

A SMART system to suit every clinic... Cattani manufacture a range of SMART suction sizes and configurations so you can be sure there is a system to suit your practice’s requirements. We offer solutions from a single chair, right though to hospital and university size applications. To have a quick look at what the different models can offer then try this PDF

If you are not sure what equipment you may need try Cattani Australia's guide

Or if you feel this may be the product for you but want some more info then try this PDF for what maintenance would be required
